Product Details:
Payment & Shipping Terms:
|
| Temperature Resistance: | -50 C Degree To 540 C Degree | Weight: | 500 G/sqm |
|---|---|---|---|
| Thickness: | 0.35 Mm | Coating: | Neoprene |
| Width: | 1m / 1.5m OEM | Color: | Black |
| Roll Length: | 50 Meter | Origin: | Hubei, China |
| Character: | Weather Resistance | ||
| High Light: | black fiberglass fabric,silicone impregnated fiberglass cloth |
||
Red Medium Duty Fire Blanket Roll Material Silicone Coated Fiberglass Fabrics
Description:
GF200P-NE265-4001 is a light-weight woven fiberglass fabric with a high quality, fire retardant neoprene rubber. This product is designed for the manufacture of flexible connector, removable insulation pads, jacket and mattresses. The material is soft and pliable and easy to sew.
Neoprene coated glass cloth is a general purpose grade glass fibre fabric, coated on both sides with neoprene to enhance technical properties. Neoprene coated glass cloth is available to buy online at PAR Direct by clicking the link above.
Parameter List:
| BASE FABRIC | Base fabric style No. GF200P | ||
| (Metric) | (English) | Test methods | |
| Weave | Plain | Plain | |
| Yarn | |||
| Warp | EC9 68 1*0 | ECG 75 1/0 | |
| Weft | EC9 68 1*0 | ECG 75 1/0 | |
| Construction | |||
| Warp | 18 ends /cm | 48 ± 3 ends/inch | |
| Weft | 12.6 picks /cm | 32 ± 3 picks/inch | |
| Weight | 200 ± 10 g/m2 | 5.8 ± 0.29 oz/yd2 | ASTM D3776-96 |
| Thickness | 0.20 ± 0.01 mm | 0.008 ± 0.0004 inch | ASTM D1777-96 |
|
|
|||
| COATED FABRIC | Coating style No. NE265-4001 | ||
| Coating | Neoprene rubber, one side | ||
| Weight | 500 ± 30 g/m2 | 14.7 ± 0.88 oz/yd2 | ASTM D3776-96 |
| Thickness | 0.33 ± 0.03 mm | 0.013 ± 0.0011 inch | ASTM D1777-96 |
| Color | Black | ||
| Fire resistance | Flame retardant | ||
| Temp resistance |
Glass fabric up to 5400C (10000F) Neoprene rubber coating up to 1500C (3600F) |
||
Typical Applications:
Binding pipes and equipment as a kind of material of resistance to aging, corrosion and oil, widely applied in various industrial fire and smoke screens, fire blanket, fire wall, fire partition and etc.
Advantage:
Good resistance to ageing.
Good weather resistance.
Chinese manufacturer price
Good chemical resistance
Good abrasion resistance
