Weatherproof Aluminum Foil Fiberglass Cloth For Insulation

Place of Origin Jiangsu, China
Brand Name Suntex
Model Number TGF580-AL122-6005
Minimum Order Quantity 1000 Square Meter/Square Meters
Price US$1- US$5 / Square Meter
Packaging Details Rolls packed in cartons loaded on pallets or according to customers' requirements.
Delivery Time 5-20 days
Payment Terms L/C, D/P, T/T
Supply Ability 300000 Meter/ Month

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Yarn Type E-Glass Alkali Content Alkali Free
Weave Type Twill Woven Weight 640g/sqm
Surface Treatment Aluminum Foil Thickness 0.75mm
Width 1m, 1.2m, 1.5m, 1.8m, 80~200cm, Or Customized Color Silver Grey
Standing Temperature 550 C Degree Property Flame Retardant
Good Features Insulation, Good Heat Reflection, Abrasion Proof Application 1 Insulation Cover, Heat Protection Cushions, Motor Vehicle Industry
Application 2 Fire Curtain, Duct, Protection For Piping Outside, Electric Prevention
High Light

coated fiberglass fabric


Aluminum Foil Fiberglass Cloth


high temperature fiberglass cloth

Leave a Message
Product Description

Aluminum Coated With Fiberglass Fabric Heat Protection Materials Protection For Piping Outside


Product Description


Aluminum foil/film laminated fiberglass fabrics

    The combination of laminating an aluminum metallic/film heat shield to a layer of protective fiberglass insulation, using fiberglass as the base cloth and special fire-resistant adhesive agent, it can protect personnel or equipment by reflecting radiant heat. Our aluminum foil coated fiberglass cloth has many excellent properties such as the smooth surface on the aluminum foil, non-water permeability, good hermetic and weather resistance, strong light reflection, good stretching resistance in length and breadth, non-breath ability.


-One side or both sides aluminum foil/film laminated available.

-The thickness of aluminum foils available from 0.0007mm to 3mm

-Width of fabrics available from 1000mm to 3000mm.



BASE FABRIC Base fabric style No. TGF580
  (Metric) (English) Test methods
Weave Plain Plain
Warp ET9 430 tex ETG 11.6
Weft ET9 430 tex ETG 11.6
Warp 8 ± 0.8 ends/cm 20 ± 2 ends/inch
Weft 5.7 ± 0.6 ends/cm 14 ± 1 ends/inch
Weight 580 ± 30 g/m2 17 ± 0.9 oz/yd2 ASTM D3776-96
Thickness 0.70 ± 0.05 mm 0.028 ± 0.002 inch ASTM D1777-96
COATED FABRIC Coating style No. AL122-6005
Coating Aluminum foil (22 microns) laminated on one side
Weight 640 ± 30 g/m2 18.82 ± 0.88 oz/yd2 ASTM D3776-96
Thickness 0.75 ± 0.04 mm 0.03 ± 0.0002 inch ASTM D1777-96
Color Silver
Flame resistance Non-combustible
Working temp

Glass fabric up to 5500C (10000F)

Aluminum foil up to 1400C (3000F)


Style No. Weight Thickness
(g/m2) Oz/yd) (mm) (inch)
GF200-AL114--6001 250 7.3 0.21 0.08
GF430-AL114--6002 470 13.8 0.42 0.016
GF580-AL122--6005 630 18.5 0.75 0.03
TGF1000-AL118--6007 1050 31 1.5 0.059
