Product Details:
Payment & Shipping Terms:
|
| Weight: | 600 G/sqm | Thickness: | 0.45 Mm |
|---|---|---|---|
| Color: | Black | Yarn Tape: | E-glass |
| Weave Tape: | Satin Weave | Width: | 1m/1.3m/1.5m/1.52m/1.55m |
| Coating: | Neoprene | Standing Temperature: | From -50℃ To 550℃ |
| High Light: | neoprene coated fiberglass,black fiberglass fabric |
||
GF431P-NE245-4005 is a medium weight fiberglass fabric coated with a high quality, fire retardant neoprene rubber. This product is designed for the manufacture of removable, reusable insulation pads, jacket and mattresses. The material is soft and pliable and easy to sew.
This product is particularly suitable for the manufacture of compensators and expansion covers
Main applications
- Flexible ductwork connector
- Welding blankets
- Other fire control systems
| BASE FABRIC | Base fabric style No. GF431P | ||
| (Metric) | (English) | Test methods | |
| Weave | 4H Satin | Crowfoot | |
| Yarn | |||
| Warp | EC9 68 1﹡2 | ECG 75 1/2 | |
| Weft | EC9 68 1﹡2 | ECG 75 1/2 | |
| Construction | |||
| Warp | 18 ± 1 ends/cm | 48 ± 3 ends/inch | ASTM D 3775-96 |
| Weft | 12.6 ± 1 picks/cm | 32 ± 3 picks/inch | ASTM D 3775-96 |
| Weight | 430 ± 30 g/m2 | 12.6 ± 0.9 oz/yd2 | ASTM D3776-96 |
| Thickness | 0.37 ± 0.06 mm | 0.015 ± 0.002 inch | ASTM D1777-96 |
| COATED FABRIC | Coating style No. NE245-4005 | ||
| Coating | Neoprene rubber , two sides | ||
| Weight | 600 ± 30 g/m2 | 17.35 ± 0.88 oz/yd2 | ASTM D3776-96 |
| Thickness | 0.47 ± 0.02 mm | 0.019 ± 0.0008 inch | ASTM D1777-96 |
| Color | Black | ||
| Fire resistance | Flame retardant | ||
| Temp resistance |
Glass fabric up to 5500C (10000F) |
||
Related Style
1. Q: Are you a factory or trading company?
A: We are a factory.
2. Q:Why do you choose us?
A: Suntex management and staff have over 20 years of cumulative experience in industrial textiles.
3. Q:What is your delivery time?
A:Generally we will within 30 days of delivery to you
4. Q:Can you product the customized goods?
A:Surely, we can be customized according to your demanding.
5. Q:What kinds of payment you accept?
A:We accept T/T, L/C ,D/P or other.
6. Q:Do you have other production?
A:Certainly,we still have Rewettable fiberglass fabric, EPDM rubber coated fiberglass fabric, Fluoride coated fiberglass
fabric, Hypalon coated fiberglass fabric, PVC coated fiberglass fabric, PVC coated polyester fiberglass Carbonized fabric,
Aluminized aramid fabric . We are looking forward to your enquiry.
