Heat resistant material silicone rubber coated fiberglass fabrics for flexible expansion joint

  • Heat resistant material silicone rubber coated fiberglass fabrics for flexible expansion joint
  • Heat resistant material silicone rubber coated fiberglass fabrics for flexible expansion joint
  • Heat resistant material silicone rubber coated fiberglass fabrics for flexible expansion joint
  • Heat resistant material silicone rubber coated fiberglass fabrics for flexible expansion joint
  • Heat resistant material silicone rubber coated fiberglass fabrics for flexible expansion joint
  • Heat resistant material silicone rubber coated fiberglass fabrics for flexible expansion joint
  • Heat resistant material silicone rubber coated fiberglass fabrics for flexible expansion joint
  • Heat resistant material silicone rubber coated fiberglass fabrics for flexible expansion joint
  • Heat resistant material silicone rubber coated fiberglass fabrics for flexible expansion joint
  • Heat resistant material silicone rubber coated fiberglass fabrics for flexible expansion joint
  • Heat resistant material silicone rubber coated fiberglass fabrics for flexible expansion joint
  • Heat resistant material silicone rubber coated fiberglass fabrics for flexible expansion joint
  • Heat resistant material silicone rubber coated fiberglass fabrics for flexible expansion joint
Place of Origin China
Brand Name SUNTEX
Certification M0
Model Number GF880P-SI254-1047
Minimum Order Quantity 500 meter
Price FOB Shanghai 2.3-7.6 $/sqm
Packaging Details Each roll in the carton, several cartons on the pallets
Delivery Time 5-15 working days
Payment Terms T/T, L/C, D/P, Western Union
Supply Ability 500000 meter per month

Contact me for free samples and coupons.

WhatsAPP:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Weight 1120 G/sqm Thickness 0.95 Mm
Color Red Yarn Tape E-glass
Weave Tape Satin Weave Width 1m/1.3m/1.5m/1.52m/1.55m
Coating Silicon Rubber Standing Temperature From -50℃ To 550℃
Highlight

fireproof fiberglass cloth

,

fire retardant cloth
Leave a Message
Product Description

Silicone coated fire-resistant fiberglass cloth from Suntex offers good resistance to extreme temperatures, being able to operate normally from -50°C to +250°C. It also has excellent weatherproof, water repellent, good chemical resistance to acids and lye, good mechanical properties for make-up.



Suntex provides one-sided/double-sided silicone coated fire-resistant fiberglass cloth with many varieties of coating weight, colors and widths for difference applications.



GF880P-SI254-1047 is a medium weight woven fiberglass fabric with a specially formulated, flame retardant silicone rubber coating which provides greater life and improved resistance to abrasion, flexing, tear and puncture.

GF880P-SI254-1047 is designed for heavy duty removable insulation pads, flange and valve covers, welding curtains, equipment covers and compensators.



Main applications

-Insulation jackets, mattress and pad

-Fabric expansion joints

-Fabric ductwork connector

-Fire doors & Fire curtains

-Welding/fire blankets

-Other fire control systems



BASE FABRIC Base fabric style No. GF880P
  (Metric) (English) Test methods
Weave 8H Satin 8H Satin
Yarn
Warp EC9 136 1*2 ECG 37 1/2
Weft EC9 136 1*2 ECG 37 1/2
Construction
Warp 18 ± 1 ends/cm 48 ± 2 ends/inch ASTM D 3775-96
Weft 14 ± 1 picks/cm 33 ± 2 picks/inch ASTM D 3775-96
Weight 880 ± 45 g/m2 26 ± 1.3 oz/yd2 ASTM D3776-96
Thickness 0.76 ± 0.06 mm 0.03 ± 0.002 inch ASTM D1777-96

COATED FABRIC Coating style No. SI254-1047
Coating Silicone rubber coated both sides
Weight 1120 ± 50 g/m2 32.9 ± 1.4 oz/yd2 ASTM D3776-96
Thickness 0.95 ± 0.05 mm 0.37 ±0.002 inch ASTM D1777-96
Color RED
Fire resistance Flame retardant
Temp resistance

Glass fabric up to 5500C

Silicone rubber coating up to 2600C





Heat resistant material silicone rubber coated fiberglass fabrics for flexible expansion joint 0

Style No. Weight Thickness color Coating
(g/m2) Oz/yd) (mm) (inch)
GF200T-SI220-1003 260 7.6 0.23 0.09 White Double side
GF430P-SI233-1015 560 16.5 0.42 0.0165 Silver Grey Double side
GF430P-SI244-1017 590 17 0.45 0.0177 Red Double side
GF430P-SI261-1020 730 21.5 0.53 0.02 Green Double side
GF66OP-SI263-1033 960 28 0.72 0.0283 Silver Grey Double side
GF660P-SI165-1023 960 28 0.72 0.0283 Black Single side
GF880-SI244-1026 1080 32 0.95 0.374 Red Double side
GF880P-SI253-1027 1120 33 1 0.039 Silver Grey Double side

Heat resistant material silicone rubber coated fiberglass fabrics for flexible expansion joint 1Heat resistant material silicone rubber coated fiberglass fabrics for flexible expansion joint 2Heat resistant material silicone rubber coated fiberglass fabrics for flexible expansion joint 3Heat resistant material silicone rubber coated fiberglass fabrics for flexible expansion joint 4Heat resistant material silicone rubber coated fiberglass fabrics for flexible expansion joint 5Heat resistant material silicone rubber coated fiberglass fabrics for flexible expansion joint 6Heat resistant material silicone rubber coated fiberglass fabrics for flexible expansion joint 7Heat resistant material silicone rubber coated fiberglass fabrics for flexible expansion joint 8Heat resistant material silicone rubber coated fiberglass fabrics for flexible expansion joint 9Heat resistant material silicone rubber coated fiberglass fabrics for flexible expansion joint 10Heat resistant material silicone rubber coated fiberglass fabrics for flexible expansion joint 11Heat resistant material silicone rubber coated fiberglass fabrics for flexible expansion joint 12

1. Q: Are you a factory or trading company?

A: We are a factory.



2. Q:Why do you choose us?

A: Suntex management and staff have over 20 years of cumulative experience in industrial textiles.



3. Q:What is your delivery time?

A:Generally we will within 30 days of delivery to you



4. Q:Can you product the customized goods?

A:Surely, we can be customized according to your demanding.



5. Q:What kinds of payment you accept?

A:We accept T/T, L/C ,D/P or other.



6. Q:Do you have other production?

A:Certainly,we still have Rewettable fiberglass fabric, EPDM rubber coated fiberglass fabric, Fluoride coated fiberglass

fabric, Hypalon coated fiberglass fabric, PVC coated fiberglass fabric, PVC coated polyester fiberglass Carbonized fabric,

Aluminized aramid fabric . We are looking forward to your enquiry.

Heat resistant material silicone rubber coated fiberglass fabrics for flexible expansion joint 13
