Grey Calcium Silicate Coated Glass Fibre Fabric Roll Fireproof Material Thermal Insulation

  • Grey Calcium Silicate Coated Glass Fibre Fabric Roll Fireproof Material Thermal Insulation
  • Grey Calcium Silicate Coated Glass Fibre Fabric Roll Fireproof Material Thermal Insulation
  • Grey Calcium Silicate Coated Glass Fibre Fabric Roll Fireproof Material Thermal Insulation
Place of Origin China
Brand Name SUNTEX
Model Number TGF1000P-CS232-5014
Minimum Order Quantity 20 rolls
Packaging Details Each roll in carton, several cartons in a pallet
Delivery Time 5-20 days
Payment Terms T/T; L/C, Paypal...
Supply Ability 500000sqm/month

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Style TGF1000P-CS232-5014 Color Grey
Weight 1100 G/SQM Thickness 1.5 Mm
Roll Length 50 M Or OEM Width 1meter / 1.5meter
Usage Heat Or Cold Resistant / Fire Protection Origin Hubei, China
Company Style Manufacturer
High Light

high temperature fabric cloth

,

high temperature fabrics
Leave a Message
Product Description

Grey Calcium Silicate Coated Glass Fibre Fabric Roll Fireproof Material Thermal Insulation



Description:



TGF1000P-CS232-5014 is a heavy weight woven fiberglass fabric with a specially formulated calcium silicate which provides a high temperature resistance surface as well as other properties for the manufacturer of smoke and fire curtains, blinds, cavity wall fire barriers, insulation covers, welding blankets and other types of smoke and other types of fire control systems.



Calcium Silicate is a natural mineral which provides a natural inorganic finish to fiberglass. This coating provides short temperature resistance of 1000C degree and increased continuous temperature resistance temperature up to 800C degree. Calcium Silicate coated fiberglass cloths increase the products’ abrasion resistance and adds to its ability to withstand direct flame, it also provide a dust suppression coating which allows for a safer work environment



Date sheet:



BASE FABRIC Base fabric style No. TGF1000
  (Metric) (English) Test methods
Weave Plain Plain
Weight 1000 ± 50 g/m2 29.4 ± 1.5 oz/yd2 ASTM D3776-96
Thickness 1.3 ± 0.1 mm 0.051 ± 0.005 inch ASTM D1777-96






COATED FABRIC Coating style No. CS232-5014
Coating Calcium silicate treated on both sides
Weight 1100 ± 50 g/m2 32.3 ± 1.5 oz/yd2 ASTM D3776-96
Thickness 1.35 ± 0.05 mm 0.053 ±0.002 inch ASTM D1777-96
Color Blue
Temp resistance 7000C 13000F



Application:



Removable insulation mattress, jacket & pad

Fire doors/smoke curtain

Dusts filter bag

Flexible expansion joints & compensators



Advantages:



High temperature resistance

Excellent anti abrasion property

Easy to be cut, sewn and fabricated

15 years experience Chinese supplier

3 part certificate insulation verified

High temperature esiatent up to 1000C

Short lead time

Manufacturer price
