Product Details
Highlight:
silicone rubber coated fiberglass fabric
,silicone coated fiberglass cloth
Temperature Resistance:
From -50 C To 550 C
Weight:
740 G/M2
Thickness:
0.53 Mm
Coating:
Silicone On Two Side
Width:
1.5 Meter
Color:
Tarmac / Yellow
Roll Length:
50 Meter
Origin:
Hubei, China
Fibreglass Cloth Roll Style:
GF430P-SI261-1020
Product Description
Weather Resistant Thermal Pipe Insulation Jacket Fibreglass Cloth Roll Silicone On Two Side Glass Fabric Textiles
Production: weather resistant thermal pipe insulation jacket fiberglass cloth
Usage: smoke curtain, thermal insulation, welding protection, heat protection quilt, expansion joints, packing materials, aerospace, marine, chemical industry, power plant, automobile manufacturer, construction, piping, oil plants
Color: red/black/white/grey/blue/yellow,or customized
Product Show
Product Details
| BASE FABRIC | Base fabric style No. GF430P | ||
| (metric) | (English) | Test methods | |
| Weave | 4H Satin | Crowfoot | |
| Yarn | |||
| Warp | EC9 68 1﹡2 | ECG 75 1/2 | |
| Weft | EC9 68 1﹡2 | ECG 75 1/2 | |
| Construction | |||
| Warp | 18 ± 1 ends/cm | 48 ± 3 ends/inch | ASTM D 3775-96 |
| Weft | 12.6 ± 1 picks/cm | 32 ± 3 picks/inch | ASTM D 3775-96 |
| Weight | 430 ± 30 g/m2 | 12.6 ± 0.9 oz/yd2 | ASTM D3776-96 |
| Thickness | 0.37 ± 0.06 mm | 0.015 ± 0.002 inch | ASTM D1777-96 |
| COATED FABRIC | Coating style No. SI261-1020 | ||
| Coating | Silicone rubber 2 sides | ||
| Weight | 730 ± 25 g/m2 | 21.5 ± 0.74 oz/yd2 | ASTM D3776-96 |
| Thickness | 0.53± 0.02 mm | 0.020 ± 0.0007 inch | ASTM D1777-96 |
| Color | Green | ||
| Fire resistance | Flame retardant | ||
| Temp resistance |
Glass fabric up to 5500C (10000F) Silicone rubber coating up to 2500C (4800F) |
||
