Heavy Duty Welding Protection Blanket Fiberglass High Temperature Fabric Cloth 2.6mm Graphite Coated

Place of Origin China
Brand Name SUNTEX
Model Number TGF2550-GP225-5020
Minimum Order Quantity 20 rolls
Packaging Details Each roll in carton, several cartons in a pallet
Delivery Time 5-20 days
Payment Terms T/T; L/C, Paypal...
Supply Ability 500000sqm/month

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Nominal Weight 1150g/sq.m Nominal Width 1000mm 1520mm
Nominal Thickness 2.6mm Color Black
Temperature Resistance /Working Temperature 750℃ 1300℉ Coating Temperature Resistance 750℃ 1300℉
Treatment Graphite Both Sides Fiberglass E-glass Texturized Woven Fabric
High Light

high temperature fabric cloth


fiberglass cloth heat resistant

Leave a Message
Product Description

Fire Resist Fabric High Temperature Fiberglass Fabric 2.6mm Graphite Coated Heavy Duty Welding Protection Blanket




Graphite coating fibergalss fabric has good resistance to fire, high temperature, abrasion and excellent tensile strength, used widely for manufacturer of gaskets, flexible expansion joints, removable jackets and other types of fire control systems.




1. Excellent certified fire resistance.

2. Easy to be used, sewn and fabricated.

4. Excellent abrasion resistance property.

5. Excellent tensile strength.

6. Thickness, unit weight, pattern, all can be customized base on your application.




Nominal weight 1150 g/sqm
Nominal Thickness 2.6 mm
Nominal width 1000mm 1520mm
Treatment Graphite
Color of coating Black
Fire resistance Excellence
Temperature resistance Basic fabric 550 ℃, Graphite coating 750 ℃.
Weave Double Twill
Fiberglass E-glass Texturized Woven Fabric




In public building : Fire door, smoke curtain, flexible ducts;

Industrial field: Welding blanket, Reusable thermal insulation shell, pad


Related Products


Style No. Weight Thickness Color Coating
g/m2 oz/yd2 mm inch
TGF880-GP235-5001 980 28.8 1.0 0.039 Black 2 sides
TGF1000-GP235-5002 1100 32.4 1.4 0.055 Black 2 sides
TGF1250-GP235-5003 1400 41.2 1.6 0.063 Black 2 sides
TGF2050-GP245-5004 2250 66 2.5 0.098 Black 2 sides
TGF1000S-GP235-5015 1180 35 1.5 0.059 Black 2 sides
TGF2550-GP225-5020 2650 78 2.6 0.102 Black 2 sides


Main products: Qualified Fiberglass fabric with silicone, PU, acrylic, neoprene, vermiculite, calcium silicate, graphite, PTFE coating.
Main application: Mainly used in the fields of fire prevention and thermal isolation, like removable thermal insulation jackets, fire curtains, welding blankets, fabric air dispersion/ventilation system, fabric expansion joint, etc.
Advertise & Exhibite: Our company participates in major professional exhibitions every year, and advertises in main search engines, professional portals, To build a world-renowned brand.
Sales Network: We do business with customers all over the world. Depends on our excellent products, over 80% of our products sold abroad, most of them export to European and American countries.
Package: 50m per roll, packed in carton, then loaded on pallet. Choose extra wood planks to protect your cargo.
Agency Policy: Customers whose quantity and rate of purchase reach certain level can be chosen to our local agent, we'll transfer sale and managerment affairs of our small customer around to agent.
Service: We belive "Customer is Supreme", all of our products can be customized, wholeday non-stop online service.
Payment Terms: 30-50% deposite after contract signed, balance paid before shipping. L/C,D/P support.
Delivery Terms: 30 days after deposite received.
Warranty Terms: One year warranty, if there're quality problems, our support team will help to solve it by consultation or technical guidance.
