0.8mm Fire Resistant Thermal Insulation Fabric For Welding Protection Blanket Roll

0.8mm Fire Resistant Thermal Insulation Fabric For Welding Protection Blanket Roll
0.8mm Fire Resistant Thermal Insulation Fabric For Welding Protection Blanket Roll 0.8mm Fire Resistant Thermal Insulation Fabric For Welding Protection Blanket Roll 0.8mm Fire Resistant Thermal Insulation Fabric For Welding Protection Blanket Roll

Large Image :  0.8mm Fire Resistant Thermal Insulation Fabric For Welding Protection Blanket Roll

Product Details:
Place of Origin: China
Brand Name: SUNTEX
Model Number: GF880-HT
Payment & Shipping Terms:
Minimum Order Quantity: 20 rolls
Packaging Details: Each roll in carton, several cartons in a pallet
Delivery Time: 5-20 days
Payment Terms: T/T; L/C, Paypal...
Supply Ability: 500000sqm/month
Detailed Product Description
Application: Fire Protective Blanket Weight: 25 Oz/yd2
Working Temperature: 550 C Color: Brown
Pattern: 8H Satin Treatment: Heat Treatment
Width: 100cm, 150cm Yarns: 9um Glass Fiber
High Light:

silicone rubber coated fiberglass cloth

,

heat reflective fabric

0.8mm Fire Resistant Thermal Insulation Fabric Welding Protection Blanket Roll



GF880-HT is a filament woven fiberglass fabric with heat treatment. Color Brown. Heat clean processing reduces the fiber airborn of the fabric,and makes it more human friendly.



GF880-HT is designed for the manufacturer of reusable fire or fire blankets,removable thermal insulation jackets, mattress, and other fire control systems.



Technical Data:



PROPERTY DATA
  (Metric) (English) Test methods
Weave 8H Satin 8H Satin
Treatment Caramelize Heat clean
Yarn
Warp EC9 33 1﹡8 ECG 150 1/8
Weft EC9 33 1﹡8 ECG 150 1/8
Construction
Warp 18 ± 1 ends/cm 48 ± 3 ends/inch ASTM D 3775-96
Weft 14 ± 1 picks/cm 33 ± 3 picks/inch ASTM D 3775-96
Weight 880 ± 60 g/m2 26 ± 1.3 oz/yd2 ASTM D3776-96
Thickness 0.8 ± 0.05 mm 0.03 ± 0.002 inch ASTM D1777-96
Standard width 101.6 ± 1 cm 40 ± 0.39 inch ASTM D3776-96
152.4 ± 1 cm 60 ± 0.39 inch
182.9 ± 1 cm 72 ± 0.39 inch

Temp resistance 5500C 10000F



Advantages:



1. Good fire resistant.M0 classification.

2. Flexible,soft, easy to be fabricated

3. Bears temperature 550C degree.



Main applications:



1. Fire blankets.

2. Welding barriers

3. Base materials for coating

0.8mm Fire Resistant Thermal Insulation Fabric For Welding Protection Blanket Roll 00.8mm Fire Resistant Thermal Insulation Fabric For Welding Protection Blanket Roll 10.8mm Fire Resistant Thermal Insulation Fabric For Welding Protection Blanket Roll 20.8mm Fire Resistant Thermal Insulation Fabric For Welding Protection Blanket Roll 3
