Product Details:
Payment & Shipping Terms:
|
| Wieght: | 1100 G/M2 | Thickness: | 1.5 Mm Thickness |
|---|---|---|---|
| Width: | 1.5 Meter Or OEM | Roll Length: | 50 Meter Or OEM |
| Color: | Grey Or OEM | Coating Material: | Calcium Silicate On 2 Side |
| Origin: | Hubei, China | Temperature Resistance: | Up To 1000 C |
| Application: | Insulation Covers | ||
| High Light: | silicone rubber coated fiberglass cloth,silicone impregnated fiberglass fabric |
||
Flame Retardant 1.4mm Thermal Insulation Fabric 700 C Degree Heat Protection
Description:
Calcium silicate coated fiberglass fabric is made calcium silicate coated glass fabric from high temperature reistance and good fiber fraying resistance. Suntex offers high quality calcium silicate coated fiberglass fabric 1000g/m2, 1200g/m2. Colors can be customized.
TGF1000P-CS233-5006 is a heavy weight woven fiberglass fabric with a specially formulated calcium silicate which provides a high temperature resistance surface as well as other properties for the manufacturer of smoke and fire curtains, blinds, cavity wall fire barriers, insulation covers, welding blankets and other types of smoke and fire control systems.
Date sheet:
| BASE FABRIC | Base fabric style No. TGF1000 | |||
| (Metric) | (English) | Test methods | ||
| Weave | Plain | Plain | ||
| Yarn | ||||
| Warp | ET9 1250 tex | ETG 4.0 | ||
| Weft | ET9 1250 tex | ETG 4.0 | ||
| Construction | ||||
| Warp | 5 ± 0.6 ends/cm | 13 ± 2 ends/inch | ASTM D 3775-96 | |
| Weft | 3 ± 0.5 picks/cm | 8 ± 1 picks/inch | ASTM D 3775-96 | |
|
|
||||
| COATED FABRIC | Coating style No. CS233-5006 | |||
| Coating | Calcium silicate treated on both sides | |||
| Weight | 1100 ± 50 g/m2 | 32.3 ± 1.5 oz/yd2 | ASTM D3776-96 | |
| Thickness | 1.5 ± 0.05 mm | 0.061 ±0.002 inch | ASTM D1777-96 | |
| Color | Grey | |||
| Temp resistance | 7000C | 13000F | ||
Application:
Removable insulation mattress, jacket & pad
Fire doors/smoke curtain
Dusts filter bag
Flexible expansion joints & compensators
Advantages:
Extreme high tempereature resistant up to 700C
Weather proofing
Chemical resistnce
High temperature resistance
Excellent anti abrasion property
Good mechanical performance
