Fire Barrier Material High Temperature Fiberglass Fabric 980g Graphite Coated Cloth Smoke Door Flexible Compensators
Place of Origin:CHINA
Brand Name:SUNTEX
Model Number:TGF880-GP235-5001
Minimum Order Quantity:1000m
Price:Negotiable
Payment Terms:L/C, D/A, D/P, T/T, Western Union,
Supply Ability:100000m per month
Product Details
Highlight:
fiberglass cloth heat resistant
,high temperature fabrics
Weight:
980g/sqm
Width:
1000mm 1520mm 1550mm 2000mm
Thickness:
1mm
Color:
Black
Weave:
Plain
Temperature Resistance /Working Temperature:
750℃ 1300℉
Coated:
Graphite Two Sides
Fiberglass:
E-glass Texturized Woven Fabric
Product Description
Fire Barrier Material High Temperature Fiberglass Fabric 980g Graphite Coated Cloth Smoke Door Flexible Compensators
Introduce
TGF880-GP235-5001 is coating with specially graphite and PU solution, that provide it very good performance to high temperature, abaration and fire. It's middle weight, can be used as middle duty welding blanket and firedoor.
Advantage
1. High temperature resistance up to 750℃.
2. Soft to be used, sewn and fabricated.
3. Good abrasion resistance and tensile strength property.
4. Thickness, weight, weave, all can be customized base on your application.
Data
| Weight | 980 g/m2 |
| Thickness | 1 mm |
| Width | 1000mm 1520mm 1550mm 2000mm |
| Coated | Graphite |
| Color | Black |
| Fire resistance | Good |
| Working temperature | Basic fabric 550 ℃, Graphite coating 750 ℃. |
| Weave | Plain |
| Yarn warp | ET9 480 tex |
| Yarn weft | ET9 480 tex |
| Construction warp | 10 ± 0.6 ends/cm ends/inch |
| Construction weft | 8 ± 0.5 ends/cm ends/inch |
| Fiberglass | E-glass Texturized Woven Fabric |
Applications
In high temperature environment: Welding blanket, Reusable thermal insulation kit, pad; fire door and smoke curtain
In Air distribution system: Expansion joint and air duct
Guarantees
All Suntex’s customers are covering by the warranty:
- Replacement. – In case of the quality of delivery was proved unsatisfied by our customer, suntex will send out a new batch to replace without delaying.
- Timely delivery. – Suntex usually keeps sufficient stocks for the standard items. It assures us to deliver the goods to the customers worldwide in time.
- Cost-effective (low price). – Suntex understands the customers’ requirements of continually lowering the purchase prices. All guys at Suntex keep in increasing work efficiency to reducing the production costs to meet the customers’ requirements of costs reduction.
- Environmental protection & human health care. – Suntex cares the human health and environmental protection. All materials used in the process of our production are harmless to the human and environment. (photos: ROHS, ASBESTOS FREE)
Related Products
| Style No. | Weight | Thickness | Color | Coating | ||
| g/m2 | oz/yd2 | mm | inch | |||
| TGF880-GP235-5001 | 980 | 28.8 | 1.0 | 0.039 | Black | 2 sides |
| TGF1000-GP235-5002 | 1100 | 32.4 | 1.4 | 0.055 | Black | 2 sides |
| TGF1250-GP235-5003 | 1400 | 41.2 | 1.6 | 0.063 | Black | 2 sides |
| TGF2050-GP245-5004 | 2250 | 66 | 2.5 | 0.098 | Black | 2 sides |
| TGF1000S-GP235-5015 | 1180 | 35 | 1.5 | 0.059 | Black | 2 sides |
| TGF2550-GP225-5020 | 2650 | 78 | 2.6 | 0.102 | Black | 2 sides |
