High Temperature Insulation Aluminum Foil Fiberglass Cloth For Heat Shielding Applications

High Temperature Insulation Aluminum Foil Fiberglass Cloth For Heat Shielding Applications
High Temperature Insulation Aluminum Foil Fiberglass Cloth For Heat Shielding Applications
video play

Large Image :  High Temperature Insulation Aluminum Foil Fiberglass Cloth For Heat Shielding Applications

Product Details:
Place of Origin: Jiangsu, China
Brand Name: Suntex
Model Number: TGF580-AL122-6005
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Fabric rolls packed in cartons loaded on pallets or according to customers' requirements.
Delivery Time: 5-20 days
Payment Terms: L/C, D/P, T/T
Supply Ability: 300000 Meter/Meters per Month
Detailed Product Description
Yarn Type: E-Glass Weave Type: Twill Woven Or Customized
Alkali Content: Alkali Free Width: 100cm,127cm,130cm,or Customized
Weight: 640g/m2 Thickness: 0.75mm
Base Material: 100% Fiberglass Good Features: High Temperature Resistant, Heat Isolation,anti-corrosion, Soundproof
Standing Temperature: 180 Degree C Color: Silver Or Customized
Coating: One Side Aluminum Foil Type: Fireproof Waterproof Insulation Fiberglass Fabric
Application 1: Heat Shields,fire Curtains,insulation Pads/ Jacket/cover/blanket Application 2: Chemical/shipbuilding Industry, Fire/welding Blanket, Pipe Protection
High Light:

aluminized fiberglass cloth

,

aluminized fiberglass fabric

High Temperature Insulation Aluminum Foil Fiberglass Cloth For Heat Shielding Applications



Product Description



    The combination of laminating an aluminum metallic/film heat shield to a layer of protective fiberglass insulation protects personnel or equipment by reflecting radiant heat. Suntex uses the high-temperature adhesive to ensure the maximum working temperature up to 150C.

-One side or both sides aluminum foil/film laminated available.

-The thickness of aluminum foils available from 0.0007mm to 0.005 mm or customized.

-Width of fabrics available from 1000mm to 1520mm, or customized.



Main applications:

1.Heat-retardant curtains or screens, heat shields

2.Thermal insulation covers, mattress, jacket, blanket, and pads

3.Welding/fire protection

4.Chemical and shipbuilding industry, piping protection

5.Other fire and smoke control systems



BASE FABRIC Base fabric style No. TGF580
  (Metric) (English) Test methods
Weave Plain Plain
Yarn
Warp ET9 430 tex ETG 11.6
Weft ET9 430 tex ETG 11.6
Construction
Warp 8 ± 0.8 ends/cm 20 ± 2 ends/inch
Weft 5.7 ± 0.6 ends/cm 14 ± 1 ends/inch
Weight 580 ± 30 g/m2 17 ± 0.9 oz/yd2 ASTM D3776-96
Thickness 0.70 ± 0.05 mm 0.028 ± 0.002 inch ASTM D1777-96

COATED FABRIC Coating style No. AL122-6005
Coating Aluminum foil (22 microns) laminated on one side
Weight 640 ± 30 g/m2 18.82 ± 0.88 oz/yd2 ASTM D3776-96
Thickness 0.75 ± 0.04 mm 0.03 ± 0.0002 inch ASTM D1777-96
Color Silver
Flame resistance Non-combustible
Working temp

Glass fabric up to 5500C (10000F)

Aluminum foil up to 1400C (3000F)


GF600C-AL118-6004

Packaging & Shipping

Packaging-&-Shipping
