2025 Fireproof Chemical Resistant Non Stick Polyurethane Coated Fiberglass Fabric / Cloth

Place of Origin:Jiangsu, China
Brand Name:Suntex
Model Number:TGF580P-PU113-2019
Minimum Order Quantity:Negotiable
Payment Terms:L/C, D/P, T/T
Supply Ability:300000 Meter/Meters per Month
Product Details
Highlight:

fiberglass fabric roll

,

high temp fabric

Yarn Type: E-Glass
Weave Type: Twill Woven Or Plain Woven Or Customized
Alkali Content: Alkali Free
Width: 1m To 2m Or Customized
Weight: 620g/m2
Thickness: 0.77mm
Base Material: 100% Fiberglass
Good Features: Fireproof, Heat Resistant, Waterproof,weatherpoof
Standing Temperature: 180°C
Color: Silver,grey,blue,black,or Customized
Coating: One Side Polyurethane(PU) Coated
Application 1: Fire Blanket, Automobile Fire Blanket, Welding Blanket
Application 2: Fire Curtain, Smoke Screen, Welding Curtain
Application 3: Expansion Joints, Fabric Air Distribution Ducts
Product Description

2025 Fireproof Chemical Resistant Non-stick Polyurethane Coated Fiberglass Fabric/Cloth

Product Description



    Suntex insulation fireproof non-stick fiberglass cloth polyurethane(PU) coated fabric is made up of woven fiberglass fabric with a waterproof polyurethane coating or laminate. The polyurethane coating is applied to two sides of the base fabric, this makes the fabric water-resistant, lightweight and flexible. Its applications include camping tents, clothing, bags, light-duty covers, fire/welding blanket, fire curtain, smoke screen, fabric ductwork connector, thermal insulation covers, flexible expansion joints, and so on.



BASE FABRIC Base fabric style No. TGF580
  (Metric) (English) Test methods
Weave Plain Plain
Yarn
Warp ET9 430 tex ETG 11.6
Weft ET9 430 tex ETG 11.6
Construction
Warp 8 ± 0.8 ends/cm 20 ± 2 ends/inch
Weft 5.7 ± 0.6 picks/cm 14 ± 1 picks/inch
Weight 580 ± 30 g/m2 17 ± 0.9 oz/yd2 ASTM D3776-96
Thickness 0.73 ± 0.037 mm 0.029 ± 0.002 inch ASTM D1777-96

COATED FABRIC Coating style No. PU113-2019
Coating Aluminum polymer and polyurethane solution, one side
Weight 620 ± 30 g/m2 18 ± 0.88 oz/yd2 ASTM D3776-96
Thickness 0.77 ± 0.04 mm 0.029 ± 0.002inch ASTM D1777-96
Color Grey
Flame resistance Flame retardant
Temp resistance

Glass fabric up to 5500C

Polyurethane coating up to 1800



2025 Fireproof Chemical Resistant Non Stick Polyurethane Coated Fiberglass Fabric / Cloth

2025 Fireproof Chemical Resistant Non Stick Polyurethane Coated Fiberglass Fabric / Cloth

2025 Fireproof Chemical Resistant Non Stick Polyurethane Coated Fiberglass Fabric / Cloth
