Fire Retardant Aluminized Glass Cloth Thermal Insulating Materials Of The Steam Heating Pipelines & Fire Suits

Fire Retardant Aluminized Glass Cloth Thermal Insulating Materials Of The Steam Heating Pipelines & Fire Suits
Fire Retardant Aluminized Glass Cloth Thermal Insulating Materials Of The Steam Heating Pipelines & Fire Suits
video play

Large Image :  Fire Retardant Aluminized Glass Cloth Thermal Insulating Materials Of The Steam Heating Pipelines & Fire Suits

Product Details:
Place of Origin: Jiangsu, China
Brand Name: Suntex
Model Number: TGF580-AL122-6005
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Fabric rolls packed in cartons loaded on pallets or according to customers' requirements.
Delivery Time: 5-20 days
Payment Terms: L/C, D/P, T/T
Supply Ability: 300000 Meter/Meters per Month
Detailed Product Description
Yarn Type: E-Glass Weave Type: Twill Woven Or Plain Woven Or Customized
Alkali Content: Alkali Free Width: 1m To 2m Or Customized
Weight: 640g/m2 Thickness: 0.75mm
Base Material: 100% Fiberglass Good Features: Fire-resistance, Anti-corrosion, Heat Isolation, Sound Absorbability
Standing Temperature: 180 Degree C Color: Silver, Or Customized
Coating: One Side Aluminum Foil Laminated Application 1: Heat Shields,fire Curtains,insulation Pads/ Jacket/cover/blanket
Application 2: Pipe Insulation, Chemical/shipbuilding Industry, Fire/welding Blanket
High Light:

aluminized fiberglass cloth

,

aluminized fiberglass fabric

Fire-retardant Aluminized Glass Cloth Thermal Insulating Materials Of The Steam Heating Pipelines & Fire Suits

Product Description



    The combination of laminating an aluminum metallic/film heat shield to a layer of protective fiberglass insulation protects personnel or equipment by reflecting radiant heat. Suntex uses the high-temperature adhesive to ensure the maximum working temperature up to 180C.

-One side or both sides aluminum foil/film laminated available.

-The thickness of aluminum foils available from 0.0007mm to 3mm or customized.

-Width of fabrics available from 1m to 2m, or customized.



Main applications:

1.Heat-retardant curtains or screens, heat shields

2.Thermal insulation covers, mattress, jacket, blanket, and pads

3.Welding/fire protection

4.Chemical and shipbuilding industry, pipe insulation, piping protection

5.Other fire and smoke control systems



BASE FABRIC Base fabric style No. TGF580
  (Metric) (English) Test methods
Weave Plain Plain
Yarn
Warp ET9 430 tex ETG 11.6
Weft ET9 430 tex ETG 11.6
Construction
Warp 8 ± 0.8 ends/cm 20 ± 2 ends/inch
Weft 5.7 ± 0.6 ends/cm 14 ± 1 ends/inch
Weight 580 ± 30 g/m2 17 ± 0.9 oz/yd2 ASTM D3776-96
Thickness 0.70 ± 0.05 mm 0.028 ± 0.002 inch ASTM D1777-96

COATED FABRIC Coating style No. AL122-6005
Coating Aluminum foil (22 microns) laminated on one side
Weight 640 ± 30 g/m2 18.82 ± 0.88 oz/yd2 ASTM D3776-96
Thickness 0.75 ± 0.04 mm 0.03 ± 0.0002 inch ASTM D1777-96
Color Silver
Flame resistance Non-combustible
Working temp

Glass fabric up to 5500C (10000F)

Aluminum foil up to 1400C (3000F)





TGF580HT-AL122-6005rl
