Product Details:
Payment & Shipping Terms:
|
| Yarn Type: | E-Glass | Alkali Content: | Alkali Free |
|---|---|---|---|
| Weave Type: | Twill Woven | Weight: | 480g/sqm |
| Thickness: | 0.4mm | Width: | 1m 1.2m 1.5m 1.8m 2m Or Customized |
| Material: | Silicone Coated Fiberglass Fabric | Standing Temperature: | -50°C To +260°C |
| Coating: | One Or Two Side Silicone Rubber | Type: | Fireproof Silicone Fabrics |
| Application: | Expansion Joints, Non-metallic Compensator, Anti-corrosion Sector | ||
| High Light: | 480g Silicone Coated Fiberglass Fabric,480g Silicone Coated Fiberglass Cloth,Insulation Jackets Silicone Coated Fiberglass Fabric |
||
Applications:
(1). Electric Insulation: fit for making products like insulation cloth and sleeves etc.
(2). Used as pipeline flexible coupling, non-metallic compensator helps toavoid damage caused by heat expansion and cold contraction.
(3). Used as inner and outer anti-corrosion layer featuring,excellent corrosion resistance, temperature resistance and high strength.
| Style No. | Weight | Thickness | Color | Coating | ||
| g/m2 | oz/yd2 | mm | inch | |||
| GF430P-SI123-1008 | 510 | 15 | 0.43 | 0.016 | Silver Grey | 1 side |
| GF430P-SI233-1015 | 510 | 15 | 0.40 | 0.016 | Silver grey | 2 sides |
| GF430P-SI233-1016 | 580 | 17 | 0.44 | 0.017 | Silver Grey | 2 sides |
| GF430P-SI244-1017 | 590 | 25 | 0.45 | 0.018 | Red | 2 sides |
| GF660P-SI264-1022 | 960 | 28 | 0.72 | 0.028 | Red | 2 sides |
| GF660P-SI165-1023 | 960 | 28 | 0.72 | 0.028 | Black | 1 side |
| TGF1000P-SI204-1041 | 1800 | 53 | 1.7 | 0.067 | Red | 2 sides |
| GF880P-SI254-1047 | 1120 | 32.9 | 0.85 | 0.033 | Red | 2 sides |
| GF1200S-SI132-1057 | 1350 | 39.8 | 1.15 | 0.045 | Blue | 1 side |
| GF660P-SI253-1083 | 900 | 35.5 | 0.7 | 0.027 | Grey | 2 sides |
| GF660P-SI204-1111 | 1260 | 37 | 0.87 | 0.034 | Red | 2 sides |
| GF430C-SI233-1153 | 580 | 17 | 0.45 | 0.017 | Grey | 2 sides |
| GF880C-SI244-1155 | 1080 | 32 | 0.9 | 0.035 | Red | 2 sides |
| GF200P-SI114-1171 | 250 | 7.37 | 0.2 | 0.008 | Red | 1 side |
