Product Details
Highlight:
0.41mm PU Coated Fiberglass Fabric
,Two Sides PU Coated Fiberglass Fabric
,0.41mm Polyurethane Coated Fiberglass Fabric
Name:
PU Coated Fiberglass Fabric
Yarn Type:
E-Glass
Thickness:
0.41mm Thickness
Weight:
460g/m2
Width:
From 1m To 2m, Or Customized
Base Material:
Fiberglass Material
Standing Temperature:
-70°C To +300°C
Good Features:
Fireproof, Thermal, Water And Oil Proof, Comfortable
Properties:
Good Resistance For Abrasion,waterproof, Allergen Resistant
Application:
Thermal Insulation And Fire Protection
Product Description
0.41mm Thickness PU Coated Fiberglass Fabric Two Sides Alkali Free
PU Coated Fiberglass Fabric is a kind of fire retardant cloth, single-sided and double-sided PU coated glass fiber cloth can withstand the temperature of 600
degrees instantaneous temperature. It has very good wear resistance and oil resistance, but also has excellent weather resistance, water resistance, solvent resistance,superior cold resistance, aging resistance
degrees instantaneous temperature. It has very good wear resistance and oil resistance, but also has excellent weather resistance, water resistance, solvent resistance,superior cold resistance, aging resistance
| BASE FABRIC | Base fabric style No. GF430P | ||
| (Metric) | (English) | Test methods | |
| Weave | 4H Satin | Crowfoot | |
| Yarn | |||
| Warp | EC9 68 1*2 | ECG 75 1/2 | |
| Weft | EC9 68 1*2 | ECG 75 1/2 | |
| Construction | |||
| Warp | 18 ± 1 ends/cm | 48 ± 3 ends/inch | ASTM D 3775-96 |
| Weft | 12.6 ± 1 picks/cm | 32 ± 3 picks/inch | ASTM D 3775-96 |
| Weight | 430 ± 30 g/m2 | 12.6 ± 0.9 oz/yd2 | ASTM D3776-96 |
| Thickness | 0.37 ± 0.06 mm | 0.015 ± 0.002 inch | ASTM D1777-96 |
| COATED FABRIC | Coating style No. PU21A-2006 | ||
| Coating | Fire retardant, high performance, blue/black polyurethane on both sides | ||
| Weight | 460 ± 20 g/m2 | 13.5 ± 0.59 oz/yd2 | ASTM D3776-96 |
| Thickness | 0.41 ± 0.03 mm | 0.017 ± 0.0012 inch | ASTM D1777-96 |
| Color | Blue/Black | ||
| Fire resistance | M0 approvals | NF92507 | |
| Temp resistance |
Glass fabric up to 5500C (10000F) Polyurethane coating up to 1800C (3560F) |
||
PU Coated Fiberglass Fabric Details
