0.7mm Polyurethane Coated Glass Fabric for welding blanket

0.7mm Polyurethane Coated Glass Fabric for welding blanket
0.7mm Polyurethane Coated Glass Fabric for welding blanket
video play

Large Image :  0.7mm Polyurethane Coated Glass Fabric for welding blanket

Product Details:
Place of Origin: Jiangsu, China
Brand Name: Suntex
Model Number: GF430P-PU21A-2006
Payment & Shipping Terms:
Minimum Order Quantity: 500 Square Meter/Square Meters
Price: US$2.5 - US$10 / Square Meter
Packaging Details: Fabric rolls packed in cartons loaded on pallets or according to customers' requirements.
Delivery Time: 5-20 days
Payment Terms: L/C, D/P, T/T
Supply Ability: 300000m/month
Detailed Product Description
Alkali Content: Alkali Free Yarn Type: E-Glass
Thickness: 0.41mm Weight: 460g/m2
Width: From 1m To 2m, Or Customized Weave Type: Twill Woven
Coating: Two Sides Polyurethane(PU) Coated Color: Blue,green,white,black,yellow,or Customized
Base Material: Fiberglass Cloth Standing Temperature: -70°C To +300°C
Good Features: Fireproof, Thermal, Water And Oil Proof, Comfortable Properties: Good Resistance For Abrasion,waterproof, Allergen Resistant
Application: Thermal Insulation And Fire Protection
High Light:

coated fiberglass cloth


welding blanket


Polyurethane Coated Glass Fabric

Product Description


PU Coated Fiberglass Fabric For Thermal Insulation And Fire Protection


    This fire-resistant fiberglass fabric is made of fiberglass fabric and polyurethane coating. It has many excellent characteristics such as excellent fire resistance. excellent wear resistance, cold resistance, water resistance, anti-ultraviolet, and mechanical properties. It can be used continuously at 180℃. Suntex can supply other colors according to customers' requirements.



Features: good rebound resilience, toughness, softness, superior resistance to wear, cold, oil, water, aging, and weather



Application: welding & fire protection, thermal insulation jackets, mattress, expansion joint belt, protective scrim of insulation wool, composite reinforcement



Working Temp: 550C


BASE FABRIC Base fabric style No. GF430P
  (Metric) (English) Test methods
Weave 4H Satin Crowfoot
Warp EC9 68 1*2 ECG 75 1/2
Weft EC9 68 1*2 ECG 75 1/2
Warp 18 ± 1 ends/cm 48 ± 3 ends/inch ASTM D 3775-96
Weft 12.6 ± 1 picks/cm 32 ± 3 picks/inch ASTM D 3775-96
Weight 430 ± 30 g/m2 12.6 ± 0.9 oz/yd2 ASTM D3776-96
Thickness 0.37 ± 0.06 mm 0.015 ± 0.002 inch ASTM D1777-96
COATED FABRIC Coating style No. PU21A-2006
Coating Fire retardant, high performance, blue/black polyurethane on both sides
Weight 460 ± 20 g/m2 13.5 ± 0.59 oz/yd2 ASTM D3776-96
Thickness 0.41 ± 0.03 mm 0.017 ± 0.0012 inch ASTM D1777-96
Color Blue/Black
Fire resistance M0 approvals NF92507
Temp resistance

Glass fabric up to 5500C (10000F)

Polyurethane coating up to 1800C (3560F)


Product Details GF430P-PU21A-2006TGF1020P-PU111-2025GF430P-PU213-2004-rl
