Fiberglass Fabric with Polyurethane Coating Twill Woven PU Coated Fiberglass Cloth Fabric
Contact me for free samples and coupons.
WhatsAPP:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Unit Weight | 32.35 Oz/sq.y | Standard Width | 1000mm 1520mm |
|---|---|---|---|
| Standard Thickness | 0.047 Inch | Colour | Black |
| Coating Temperature Resistance | 180℃ 350℉ | Basic Fabric Temperature Resistance | 550℃ 1000℉ |
| Coating | Polyurethane 2 Sides | ||
| Highlight | Polyurethane Coating,coated fiberglass fabric,thermal insulation fabric |
||
Product Description
Fiberglass Welding PU Coated Fiberglass Fabric Air Distribution Ducts 0.21mm Fiberglass Insulation Rolls
Introduce
TGF1000P-PU225-2056 is a heavy weight texturized fiberglass fabric with a specially formulated polyurethane aluminum polymer, provide good hand, minimal dust, and ease of application. It’s used for welding blanket,flexible expansion joint, removable jackets and other types of fire control systems.
Advantage
1. Well certified fire resistance.
2. End users can choose the favority face.
3. Easy to be applied, sewn and fabricated.
4. Well abrasion resistance property.
5. Well tensile strength.
6. Nominal Thickness, unit weight, pattern, all can be customized base on your use method.
Data
| Total weight | 32.35 oz/y2 |
| Standard Thickness | 0.047 inch |
| Standard width | 1000mm 1520mm |
| Coating | Polyurethane |
| Colour of coating | Black |
| Fire resistance | Well |
| Coating temperature resistance | PU coating 180 ℃ |
| Basic fabric working temperature | Basic fabric 550 ℃ |
| Weave/Pattern | Plain |
| Fiberglass | E-glass Texturized Woven Fiberglass |
Applications
Fire curtain
Welding blanket
Compensator
Removable heat insulation kit
Heat insulation mat
Fabric duct
Related Products
| Style No. | Weight | Thickness | Color | Coating | ||
| g/m2 | oz/yd2 | mm | inch | |||
| GF200P-PU210-2001 | 220 | 6.5 | 0.21 | 0.0082 | White | 2 sides |
| GF430P-PU213-2004 | 460 | 13.5 | 0.41 | 0.0161 | Silver grey | 2 sides |
| GF430P—PU213-2005 | 460 | 13.5 | 0.40 | 0.015 | Silver Grey | 2 sides |
| GF430P-PU21A-2006 | 460 | 13.5 | 0.41 | 0.0161 | Blue/Black | 2 sides |
| GF430P—PU21B-2007 | 460 | 13.5 | 0.40 | 0.015 | Grey White | 2 sides |
| GF430P-PU223-2010 | 490 | 14.5 | 0.45 | 0.0177 | Blue/Black | 2 sides |
| GF660—PU223-2016 | 720 | 21 | 0.71 | 0.0275 | Silver Grey | 2 sides |
| TGF580-PU113-2019 | 620 | 18.3 | 0.77 | 0.0303 | Silver grey | 1 side |
| GF800C-PU223-2023 | 880 | 26 | 0.9 | 0.0354 | Silver grey | 2 sides |
| TGF1020—PU111-2025 | 1070 | 31.5 | 1.5 | 0.0590 | Green | 1 side |
| GF660S-PU213-2036 | 710 | 20.9 | 0.7 | 0.0276 | Silver grey | 2 sides |
| GF660S—PU113-2040 | 790 | 23 | 0.70 | 0.027 | Grey | 1 side |
| SL600-PU113-2044 | 630 | 18.6 | 0.7 | 0.0276 | Silver grey | 1 side |
| TGF1000P-PU223-2049 | 1100 | 32.4 | 1.2 | 0.0472 | Silver grey | 2 sides |
