Quality High Temperature Resistant Vermiculite Coated Fiberglass Fabric factory

High Temperature Resistant Vermiculite Coated Fiberglass Fabric

Name: High Temperature Resistant Vermiculite Coated Fiberglass Fabric
Brand: Suntex Composite Industrial Co.,Ltd.
SKU: TGF1000-VE226-5008
Price: 10.00 USD
Availability: InStock

Place of Origin:China

Brand Name:SUNTEX

Model Number:TGF1000-VE226-5008

Minimum Order Quantity:20 rolls

Payment Terms:T/T; L/C, Paypal...

Supply Ability:500000sqm/month

Product Details

Highlight:

High Temperature Resistant Fiberglass Fabric

,

Vermiculite Coated Fiberglass Fabric

Nominal Weight: 1070 G/M2

Nominal Width: 1.5 M

Nominal Thickness: 1.4mm

Color: Brown / Yellow

Temperature Resistance /Working Temperature: Up To 1000℃

Treatment: Vermiculite On The Both Side

Appllication: Heavy Duty Welding Protection

Usage: Fire Resistant

Product Description

High Temperature Resistant Vermiculite Coated Fiberglass Fabric For Heat Shield And Containment

Introduce

TGF1000-VE226-5008 is a heavy weight woven texturized fiberglass fabric impregnated with specially formulated vermiculite dispensers which provides high temperature and abrasion resistance properties for the manufacturer of welding protection, gaskets, flexible expansion joints, removable jackets and other types of fire control systems.

Advantage

1. Excellent certified fire resistance.

2. Extreme high temperature resistant .

3. Easy to be used, sewn and fabricated.

4. Excellent abrasion resistance property.

5. Excellent tensile strength.

6. Thickness, unit weight, weave, all can be customized base on your use method.

High Temperature Resistant Vermiculite Coated Fiberglass Fabric

Technical Data

BASE FABRIC	Base fabric style No. TGF1000
	(Metric)	(English)	Test methods
Weave	Plain	Plain

COATED FABRIC	Coating style No. VE226-5008
Coating	Vermiculite impregnated on both sides
Weight	1070 ± 50 g/m²	32 ± 1.5 oz/yd²	ASTM D3776-96
Thickness	1.40 ± 0.05 mm	0.055 ±0.002 inch	ASTM D1777-96
Color	Brown (Yellow)
Temp resistance	550⁰C for basic fabric 800⁰C for the coating	1400⁰F

Applications

Fire blanket

Smoke door

Flexible sleeve

Reusable thermal insulation sheath

Thermal insulation mattress

Flexible duct
