Custom Thermal Insulation Jacket 1000°C Resistance 25-100mm Thick

Place of Origin	Jiangsu, China
Brand Name	Suntex
Model Number	fiberglass removable insulation jacket
Minimum Order Quantity	Negotiable
Price	Negotiable
Packaging Details	Packed in cartons loaded on pallets or according to customers' requirements.
Delivery Time	5-20 days
Payment Terms	L/C,D/P,T/T
Supply Ability	200000 Pieces/ month

Contact me for free samples and coupons.

WhatsAPP:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details

Material	Aluminum-foil,glassfiber And High Temperature Resistance Cloth	Yarn Type	E-Glass
Alkali Content	Alkali Free	Weave Type	Twill
Weight	From 200 To 2000 Gram/sq.mtr	Thickness	25-100mm
Width	1m 1.2m 1.5m 1.8m 2m Or Customized	Colors	Red,grey,black,green,and Customed Colors
Temperature Resistance	-70C~+1000 C	Size	Be Customized According To Different Shapes And Sizes Of The Equipment
Fabrics For	Removable Thermal Insulation Pads,jackets	Good Features	Excellent Insulation, Water And Oil Proofing, Easy To Clean
Application 1	Heat Preservation And Insulation On Pipes, Elbow, Flange, Tees	Application 2	Chemical Reactors, Turbine Suits, Heat Exchanges, Exhaust Pipe
Highlight	custom thermal insulation jacket , 1000°C resistant insulation fabric , 25-100mm thick thermal jacket

You can tick the products you need and communicate with us in the message board.

Leave a Message

Product Description

Silicone Rubber Coated Glass Fabric for Reusable Insulation Blankets & Pads

Customized Reusable Fiberglass Thermal Cover Removable Insulation Jacket

Suntex removable insulation jackets are constructed with glass fiber and high-temperature resistant aluminum foil or silicone cloth. The three-layer design includes inner, insulation, and protective layers, capable of withstanding temperatures up to 1000°C.

Key Advantages:

Excellent thermal insulation properties
Water and oil resistant
Multi-layer protection system
Anti-corrosion and easy to clean
Flexible and pollution-free
Fully customizable to equipment specifications

Applications

Removable thermal insulation covers and blankets
Injection molding and extrusion machines
Molds and dies protection
Pipe insulation for elbows, flanges, and tees
Chemical reactor insulation
Turbine suits for thermal and nuclear power plants
Gas turbine suits and engine exhaust systems
Heat exchanger insulation

Fabric Specifications for Thermal Insulation

Style No.	Base Fabric	Coatings	Color	Weight (g/m²)	Thickness (mm)	Temp. (°C)
GF430P-SI1413	Fiberglass	Silicone	Silver grey	510	0.4	260
GF430P-SI2423	Fiberglass	Silicone	Silver grey	560	0.45	260
GF660P-SI2453	Fiberglass	Silicone	Silver grey	960	0.76	260
GF880P-SI2463	Fiberglass	Silicone	Silver grey	1380	1.25	260
GF600-WS210	Fiberglass	Weave-locked	Green	630	0.6	550
GF800-WS212	Fiberglass	Weave-locked	Blue	830	0.75	550
GF430-PTFE213E	Fiberglass	PTFE	Grey/Black	530	0.45	550
GF430-AL1110	Fiberglass	Aluminum Foil	Silver	470	0.4	550
GF430-AL1300	Fiberglass	Aluminized polymer film	Silver	450	0.4	550
TGF1000-GP225	Fiberglass	Graphite	Black	1100	1.5	700
TGF2050-GF235	Fiberglass	Graphite	Black	2270	3.5	700
TGF880-GP225	Fiberglass	Graphite	Black	980	1	700
TGF1000-VE226	Fiberglass	Vermiculite	Tan	1080	1.5	750
TGF1000-CS2110	Fiberglass	Calcium Silicate	White	1080	1.5	700
TGF1000-CS2111	Fiberglass	Calcium Silicate	Green	1080	1.5	700
TGF1000-CS2112	Fiberglass	Calcium Silicate	Blue	1080	1.5	700
