Durable High Temperature Fiberglass Cloth with 1000°C Heat Resistance and Vermiculite Coating for Chemical Resistant Fire Barrier Applications
Place of Origin:Jiangsu, China
Brand Name:Suntex
Model Number:SL600
Minimum Order Quantity:Negotiable
Price:Negotiable
Payment Terms:L/C, D/P, T/T
Supply Ability:300000m/month
Product Details
Highlight:
1000°C Heat Resistance High Temperature Fiberglass Cloth
,Vermiculite Coated Silica Fiberglass Fabric
,Chemical Resistant Fire Barrier Fabric
Alkali Content:
Alkali Free
Yarn Type:
E-Glass
Thickness:
0.65mm
Weight:
600g/m2
Width:
From 1m To 2m Or Customized
Weave Type:
Twill Woven Or Plain Woven Or Customized
Coating:
Two Sides Vermiculite Coated
Color:
Brown/yellow
Base Material:
Silica Fiberglass Cloth
Standing Temperature:
Up To 1000 Degree C
Good Features:
High Temperature Resistance, Good Flame Retardant Ability
Properties:
Weatherproof, Water Repellent, Good Chemical Resistance
Application 1:
Welding And Molten Metal Splash Protection, Heat And Flame Shielding
Application 2:
Chemical Plants, Oil Refineries, Ports, And Industry Fields
Product Description
High Temperature Silica Fiberglass Cloth Fire Barrier Fire Blanket Material
Product Description
SL 600 is a medium weight of 96% content silica fabric. SL 600 is excellent for very high temperature resistance and fire resistance.
The application is for insulation covers, padding, lagging, welding blanket, fire curtain, and other heavy duty fire control system.
SL 600 is suitable for coating with different elastomers and polymers.
Good features:
--Silicone dioxide content >96%
--Extremely high-temperature resistance up to 1000 C
--Good anti-abrasion, good chemical resistance, easy to be cut, sewn and fabricated
--Excellent chemical resistance
--Soft and pliable
--Excellent anti-abrasion property
-- Asbestos-free, halogen-free
| BASE FABRIC | Base fabric style No. SL600 | ||
| (Metric) | (English) | Test methods | |
| Weave | 8H Satin | 8H Satin | |
| Yarn | |||
| Warp | EC9 136 1*2 tex | ECG 37 1/2 | |
| Weft | EC9 136 1*2 tex | ECG 37 1/2 | |
| Construction | |||
| Warp | 19 ± 1 ends/cm | 48 ± 2 ends/inch | ASTM D 3775-96 |
| Weft | 14 ± 1 picks/cm | 36 ± 2 picks/inch | ASTM D 3775-96 |
| Weight | 600 ± 30 g/m2 | 17.6 ± 0.8 oz/yd2 | ASTM D3776-96 |
| Thickness | 0.65 ± 0.08 mm | 0.025 ± 0.003 inch | ASTM D1777-96 |
| COATED FABRIC | Coating style No. VE216-5021 | ||
| Coating | Vermiculite impregnated on both sides | ||
| Weight | 620 ± 30 g/m2 | 18.24 ± 0.8 oz/yd2 | ASTM D3776-96 |
| Thickness | 0.68 ± 0.06 mm | 0.027 ±0.002 inch | ASTM D1777-96 |
| Color | Brown | ||
| Temp resistance |
The maximum working temperature at 1200 0C The peak Temp.(melt point) 1500 0C |
||
