Industrial Fire Blanket Roll with 1000℃ Temperature Resistance and Vermiculite Coating for Heavy Duty Welding Protection

Place of Origin:CHINA
Brand Name:SUNTEX
Model Number:TGF1000-VE226-5008
Minimum Order Quantity:1000m
Payment Terms:L/C, D/A, D/P, T/T, Western Union,
Supply Ability:100000m per month
Product Details
Highlight:

1000℃ Temperature Resistance Fire Blanket

,

Vermiculite Coated Industrial Fire Blanket Roll

,

Heavy Duty Welding Protection Fire Protection Blanket
Nominal Weight: 1070 G/sq.m
Nominal Width: 1000mm 1520mm 1550mm
Nominal Thickness: 1.4mm
Industrial Fire Blanket Roll Color: Brown
Temperature Resistance /Working Temperature: 1000℃
Basic Fabric Temperature Resistance: 550℃ 1000℉
Treatment: Vermiculite On The Both Side
Appllication: Heavy Duty Welding Protection
Usage: Fire Resistant
Product Description

1.3mm Heavy Duty Fire Protection Blanket Vermiculite Glassfiber Cloth 800 C Heat Resistant



Introduce



TGF1000-VE226-5008 is a heavy weight woven texturized fiberglass fabric impregnated with specially formulated vermiculite dispensers which provides high temperature and abrasion resistance properties for the manufacturer of welding protection, gaskets, flexible expansion joints, removable jackets and other types of fire control systems.



Advantage



1. Excellent certified fire resistance.

2. Extreme high temperature resistant .

3. Excellent tensile strength.

4. Thickness, unit weight, weave, all can be customized base on your use method.



Industrial Fire Blanket Roll with 1000℃ Temperature Resistance and Vermiculite Coating for Heavy Duty Welding Protection



Data



BASE FABRIC Base fabric style No. TGF1000
  (Metric) (English) Test methods
Weave Plain Plain
Yarn
Warp ET9 1250 tex ETG 4.0
Weft ET9 1250 tex ETG 4.0
Construction
Warp 5 ± 0.5 ends/cm 13 ± 2 ends/inch ASTM D 3775-96
Weft 3 ± 0.3 picks/cm 8 ± 1 picks/inch ASTM D 3775-96
Weight 1000 ± 50 g/m2 29.41 ± 1.5 oz/yd2 ASTM D3776-96
Thickness 1.3 ± 0.1 mm 0.05 ± 0.005 inch ASTM D1777-96




COATED FABRIC Coating style No. VE226-5008
Coating Vermiculite impregnated on both sides
Weight 1070 ± 50 g/m2 32 ± 1.5 oz/yd2 ASTM D3776-96
Thickness 1.40 ± 0.05 mm 0.055 ±0.002 inch ASTM D1777-96
Color Brown (Yellow)
Temp resistance

5500C for basic fabric

8000C for the coating



14000F





Applications



Fire blanket

Smoke door

Flexible sleeve

Reusable thermal insulation sheath

Thermal insulation mattress

Flexible duct

Industrial Fire Blanket Roll with 1000℃ Temperature Resistance and Vermiculite Coating for Heavy Duty Welding Protection



Industrial Fire Blanket Roll with 1000℃ Temperature Resistance and Vermiculite Coating for Heavy Duty Welding Protection

Industrial Fire Blanket Roll with 1000℃ Temperature Resistance and Vermiculite Coating for Heavy Duty Welding Protection

Industrial Fire Blanket Roll with 1000℃ Temperature Resistance and Vermiculite Coating for Heavy Duty Welding ProtectionIndustrial Fire Blanket Roll with 1000℃ Temperature Resistance and Vermiculite Coating for Heavy Duty Welding Protection



Industrial Fire Blanket Roll with 1000℃ Temperature Resistance and Vermiculite Coating for Heavy Duty Welding Protection

Industrial Fire Blanket Roll with 1000℃ Temperature Resistance and Vermiculite Coating for Heavy Duty Welding ProtectionIndustrial Fire Blanket Roll with 1000℃ Temperature Resistance and Vermiculite Coating for Heavy Duty Welding Protection
