Product Details:
Payment & Shipping Terms:
|
| Weight: | 560 G/M2 | Thickness: | 0.42 Mm |
|---|---|---|---|
| Color: | Silver Grey | Yarn Tape: | E-glass |
| Width: | 1.5 Meter | Coating: | Grey Silicon Rubber On Two Side |
| Standing Temperature: | From -50℃ To 550℃ | Origin: | China |
| Roll Length: | 50 Meter | Welding Duty: | Medium |
| High Light: | silicone rubber coated fiberglass cloth,silicone impregnated fiberglass fabric |
||
Medium Duty Safety Blanket Fabrics Fire/ Flame/ Spark Resistant Material
Description:
Silicone Coated Fiberglass fabric Core-Tex silicone fiberglass fabric takes high temperature, strength, and corrosion resistance fiberglass fabric as the basic fabric, and compounded by silicone rubber after the special craft (impregnating or rolling).Silicone fiberglass fabric is a kind of high performance and multifunction composite materials, it's widely used in Aerospace, Chemical, Petroleum, Large Power Generation Equipment, Machinery, Metallurgy, Electrical Insulation, Building, Transportation and other fields.
Parameter List:
| BASE FABRIC | Base fabric style No. GF430P | ||
| (metric) | (English) | Test methods | |
| Weave | 4H Satin | Crowfoot | |
| COATED FABRIC | Coating style No. SI233-1015 | ||
| Coating | Silicone rubber 2 sides | ||
| Weight | 510 ± 25 g/m2 | 15 ± 0.74 oz/yd2 | ASTM E84-12 |
| Thickness | 0.40± 0.02 mm | 0.016 ± 0.0007 inch | ASTM E84-12 |
| Color | grey | ||
| Fire resistance | M0 | ||
| Temp resistance |
Glass fabric up to 5500C (10000F) Silicone rubber coating up to 2500C (4800F) |
||
Application:
Insulation jackets, mattress and pad
Fabric expansion joints
Fabric ductwork connector
Fire doors & Fire curtains
Welding/fire blankets
Other fire control systems
Features:
Excellent non-stick properties
Water and fire protection
Good Chemical Resistance
Superior Flex and Abrasion Resistance
